12" Touch W/O Operating System DC Contactor Siemens 6av7800-0bb10-1aa0

পণ্যের বিবরণ:

উৎপত্তি স্থল:	China
পরিচিতিমুলক নাম:	SIEMENS
মডেল নম্বার:	6AV7800-0BB10-1AA0

প্রদান:

ন্যূনতম চাহিদার পরিমাণ:	2 sets
প্যাকেজিং বিবরণ:	Wooden box packing
ডেলিভারি সময়:	15 days after signing the contract
পরিশোধের শর্ত:	T/T
যোগানের ক্ষমতা:	1000sets

যোগাযোগ

বিস্তারিত পণ্যের বর্ণনা

MODEL:

6AV7800-0BB10-1AA0

Design of display:

12" TFT touch

Screen diagonal:

12 in

লক্ষণীয় করা:

dc motor contactor

electrical contactor

SIEMENS 6AV7800-0BB10-1AA0 SIMATIC PANEL PC 677 12" TOUCH W/O OPERATING SYSTEM

Name: 12" Touch W/O Operating System DC Contactor Siemens 6av7800-0bb10-1aa0
Brand: SIEMENS
SKU: 6AV7800-0BB10-1AA0
Rating: 5 (174 reviews)

echnical data

		* SPARE PART* SIMATIC PANEL PC 677 12" TOUCH; 800X600; STANDARD AC110-230V, POWER CABLE EUROPE PENTIUM M770/1.6 GHZ; 533 MHZ FSB; 2MB SLC; 512MB DDR266 SDRAM (1X512MB); 80 GBYTE SATA HARD DRIVE (3.5") DVD-ROM; W/O OPERATING SYSTEM
Display
Design of display		12" TFT touch
Screen diagonal		12 in
Resolution (pixels)
● Horizontal image resolution		800 Pixel
● Vertical image resolution		600 Pixel
General features
● Expansion components		Uninterruptible power supply (USP), SIMATIC NET communication modules
Backlighting
● MTBF backlighting (at 25 °C)		50 000 h
Control elements
Input device
● Mouse, at front		No
Keyboard fonts
● Function keys		No
● alphanumeric keyboard		No
Touch operation
● Design as touch screen		Yes
Installation type/mounting
central design		Yes
distributed design		Yes; by means of remote kit
maximum permissible installation angle +/-		20°
Supply voltage
Type of supply voltage		110/230 V AC (autorange) 50/60 Hz; optional 24 V DC
Line frequency
● Rated value 50 Hz		Yes
● Rated value 60 Hz		Yes
Power loss
In full configuration		140W max. (15W included per slot)
Processor
Processor type		Intel Pentium M Technology (2nd Generation); Intel Celeron M 370, 1.5 GHz, 400 MHz FSB, 1MB SLC; Intel Pentium M 730, 1.6 GHz, 533 MHz FSB, 2MB SLC; Intel Pentium M 760, 2.0 GHz, 533 MHz FSB, 2MB SLC
Drives
Optical drives		optional: DVD-ROM or DVD±R±RW combi drive; on rear, can be operated from side
Diskette drive		optional: via external USB floppy disk drive
Hard disk		3.5" SATA-RAID hard disk ≥ 40 GB, optional ≥ 80 GB, optional: 2x 2.5" SATA hard disk module(≥ 60GB). RAID1 controller on board. All drives with vibration-resistant mountings.
Memory
Type of memory		DDR2-533
Main memory		256 MB to 2 GB
Capacity of main memory, max.		2 048 Mbyte
Hardware configuration
Slots
● free slots		2x PCI (slots with board retainer), 1x slot for Compact Flash Card
● Number of PCI slots		2
● Number of compact flash slots		1
Interfaces
PROFIBUS/MPI		onboard, electrically isolated, max. 12 Mbps, no plug-in card necessary, CP 5611-compatible
USB port		1x at front, 4x at rear, USB 2.0 (500 mA)
Connection for keyboard/mouse		USB / USB
serial interface		COM1: 1 x V.24 (RS232)
parallel interface		optional: via PCI card
Video interfaces
● Graphics interface		DVI-I usable for additional display unit (VGA via adapter); color depth 32 bits, 8 to 128 MB Shared Memory
