140CPU65160 Modicon Quantum PLC / CPU Single Slot 80486 Processor With Mathematical

ব্র্যান্ড নাম:	Schneider
মডেল নম্বর:	40CPU65150C
MOQ:	1
মূল্য:	Negotiations

বিস্তারিত তথ্য

পণ্যের বর্ণনা

বিস্তারিত তথ্য

Type:

Modicon Quantum Automation Platform

Product Or Component Type:

Unity Processor

Clock Frequency:

266 MHz

Packaging Details:

New original box

বিশেষভাবে তুলে ধরা:

Modicon Quantum PLC CPU

80486 processor PLC

single slot PLC

পণ্যের বর্ণনা

140CPU65160 Modicon Quantum PLC / CPU Single Slot 80486 Processor With Mathematical

Product Attributes

Type	Modicon Quantum Automation Platform
Product Or Component Type	Unity Processor
Clock Frequency	266 MHz

Quick Details

SCHNEIDER ELECTRIC
MODICON
140CPU65160
UNITY PROCESSOR
QUANTUM
1024KB
266MHZ
AVAILABLE
REBUILT SURPLUS
NEVER USED SURPLUS
Weight: 2kg

New one with one year warranty and used one with six months warranty

More Information

Unity Processor Modicon Quantum - 1024 Kb - 266Mhz

Quantum | 140CPU65160 | Modicon | 140 CPU 651 60 | Processor UNITY W/ 2048/7168K Ethernet

The 140 CPU 651 50, 140 CPU 651 60 and 140 CPU 652 60 processors have the following on the front panel:

An RJ45 connector for the connection to the Modbus bus
A type B female USB connector for connecting the programming PC
A 9-way female SUB-D connector for the connection to the Modbus Plus network
Two slots for PCMCIA memory extension cards
Two LEDs marked COM and ERR
An RJ45 connector for the connection to the Ethernet network

Specifications

Manufacturer:	Modicon Quantum
Series:	Quantum CPUs
Weight:	2 lb
Product or component:	Unity processor
Clock frequency:	266 MHz
Number of slots:	10 \| 16 \| 2 \| 4 \| 6
Number of racks:	2 - local rack(s)
Number of distributed I/O station:	63 station(s) - 1 rack(s) - 3 distributed network(s)
Number of remote I/O station:	31 - 2 remote rack(s)
Discrete I/O number:	8000 inputs, 8000 outputs - distributed - per network \| 31744 inputs, 31744 outputs - remote \| Unlimited (26 slots max) - local
Analogue I/O number:	Unlimited (26 slots max) - local \| 500 inputs, 500 outputs - distributed - per network \| 1984 inputs,1984 outputs - remote
Application specific I/O:	Accurate time stamping \| Counter \| High-speed interrupt inputs \| Serial link
Number of optional modules:	6 (Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max)
Maximum number of connections:	Unlimited (AS-Interface) - local \| 6 (Profibus DP) - local \| 6 (Modbus Plus) - local \| 6 (Ethernet TCP/IP) - local \| 4 (AS-Interface) - remote \| 2 (AS-Interface) - distributed \| 1 (USB) \| 1 (Modbus) - RS232/485 Modbus/ASCII
Integrated connection type:	1 Ethernet TCP/IP \| 1 Modbus \| 1 Modbus Plus \| 1 USB
Checks:	Process control
Memory description:	Expandable 8 MB - file storage with PCMCIA card \| Expandable 7168 kB - program with PCMCIA card \| Internal RAM 768 kB
Switch function:	Key switch memory port on/off
Application structure:	4 auxiliary tasks \| 32 timer interrupt tasks \| 128 interrupt tasks \| 128 I/O interrupt tasks \| 1 periodic fast task \| 1 cyclic/periodic master task
Execution time per instruction:	0.48...0.56 µs floating points \| 0.0525...0.075 µs Boolean \| 0.045...0.06 µs on word \| 0.045...0.06 µs on fixed-point arithmetic
Execution time for 1 K instruction:	9.91 65% Boolean and 35% numerical \| 10.28 100% Boolean
System overhead:	1 ms - master task \| 0.2 ms - fast task
Bus current requirement:	2160 mA
Local signalling:	1 LED red for Ethernet collision \| 1 LED green for Ethernet activity (COM)
Electrical connection:	1 female connector, connector type: SUB-D 9 for connecting to the Modbus Plus network \| 1 connector, connector type: RJ45 for connecting Modbus bus \| 1 connector, connector type: RJ45 for connecting Ethernet network \| 1 connector, connector type: MT-RJ (fiber optic) for interconnecting primary and secondary PLCs (hot standby architecture)
